OSHA Hazard Communication Standard (HCS) Pictograms

Posted On: February 13, 2025

Learn about hazards communications pictograms standards

What Are Hazard Communication Standard Pictograms?

Hazard Communication (HazCom) Standard pictograms are standardized symbols required by OSHA under the Hazard Communication Standard (HCS), aligned with the Globally Harmonized System (GHS). These pictograms appear on Safety Data Sheets (SDS) and chemical labels to communicate physical, health, and environmental hazards, helping workers quickly identify potential dangers.


OSHA’s Hazard Communication Standard (HCS)

The Hazard Communication Standard (HCS) requires pictograms on labels to alert users to potential chemical hazards. Each pictogram is a symbol on a white background with a red border, representing a specific hazard. The selection of pictograms depends on the chemical’s hazard classification, and each appears only once on a label, even if multiple hazards share the same symbol.

OSHA’s HCS aligns with the Globally Harmonized System (GHS) to maintain consistency in chemical hazard labeling. Employers must train workers on these pictograms and their use to contribute to a safer workplace.


The Nine Hazard Communication Standard Pictograms

OSHA’s Hazard Communication Standard (HCS) includes nine pictograms, each representing specific chemical hazards

  • Health Hazard: Used for chemicals that may cause cancer (carcinogen), genetic mutations (mutagenicity), reproductive harm, respiratory sensitization, organ damage, or aspiration toxicity.
  • Flame: Indicates flammable substances, pyrophorics, self-heating materials, chemicals that emit flammable gas, self-reactive substances, and organic peroxides.
  • Exclamation Mark: Represents chemicals that may cause skin and eye irritation, skin sensitization, narcotic effects, respiratory irritation, or acute toxicity (harmful). Also used for ozone layer hazards (non-mandatory).
  • Gas Cylinder: Identifies gases under pressure, including compressed, liquefied, refrigerated, and dissolved gases.
  • Corrosion: Signifies chemicals that cause severe skin burns, eye damage, or metal corrosion.
  • Exploding Bomb: Marks explosive substances, self-reactive chemicals, and organic peroxides that may explode under certain conditions.
  • Flame Over Circle: Denotes oxidizers, which can intensify fires by releasing oxygen.
  • Skull and Crossbones: Indicates acute toxicity, meaning exposure to even small amounts can cause severe illness or death.
  • Environment (Non-Mandatory): Used for chemicals that can harm aquatic life, either short-term or long-term.
Pictograms hazards signs
Hazard Communication Pictograms

$29.95

Register Now
Pictograms hazards signs

Importance of Hazard Communication Training

Workers must be trained to understand HazCom pictograms and the hazards associated with chemicals. This training helps them read Safety Data Sheets (SDS), follow safe handling procedures, and take necessary precautions to minimize risks. Without proper training, workers may not be aware of potential dangers, increasing the risk of accidents and exposure to harmful substances.


Hazard Communication Pictograms Training Online

OSHA Training offers online Hazard Communication Pictograms training, allowing workers to learn at their own pace while meeting compliance requirements. This training helps employees identify hazards, read labels and SDS, and understand protective measures when handling hazardous materials.


Compliance and Workplace Safety

To comply with OSHA regulations and maintain a safe work environment, employers should:


Conclusion

Hazard Communication pictograms help workers identify chemical hazards and handle materials safely. Clear labeling, accessible Safety Data Sheets (SDS), and proper training help lower the risk of chemical-related injuries and keep workplaces in line with OSHA’s Hazard Communication Standard. Employers should focus on training and hazard awareness to create a safer work environment and protect workers from exposure.



Written By: Muntaha Islam
